3000 LPH RO Plant

Get a Price/Quote

MOQ : 1 Unit

3000 LPH RO Plant Specification

Efficiency (%)
Up to 98%

Technology
Reverse Osmosis (RO) with UF/UV optional

Water Out Conductivity
<20 S/cm

Recycle Rate
60% - 75%

Power Consumption
5 to 6 kW

Water in conductivity
<2000 S/cm

Pump Type
High Pressure SS Pump

Frequency
50 Hz

Usage & Applications
Water Purification for Industrial, Commercial and Institutional Use

Ph Level
6.5 - 8.5

Feature
Skid Mounted, Low Maintenance, High Efficiency

Flow Rate
3000 Liters per hour

Noise Level
<70 dB

Water Source
Borewell/Tap Water/Municipal Supply

Volume
3000 Liters/hour

Drive Type
Electric Motor

Purity Level
Up to 99.5%

Product Type
Reverse Osmosis Plant

Power Source
Electric

Voltage
380V / 415V, 3 Phase, 50 Hz

Material
Stainless Steel / FRP

Automatic Grade
Automatic

Filter Type
Multigrade Sand, Activated Carbon, Micron Filtration

Capacity
3000 LPH

Installation Type
Prefabricated / Skid Mounted

RO Membrane Element
8" X 40" Polyamide Membrane (4/5 units depending on design)

Inlet/Outlet Connection Size
1.5 inch / 2 inch

Dimension (L x W x H)
Approx. 2500 mm x 1200 mm x 1800 mm

Feed Water TDS
Up to 2000 ppm

System Recovery Rate
60% - 70%

Operating Pressure
8-16 kg/cm2

Post-Treatment Options
UV Sterilization & Ozonation (Optional)

Pre-Treatment
Multigrade Sand Filter, Activated Carbon Filter, Antiscalant Dosing

Piping & Fittings
UPVC/SS304 as per requirement

Ambient Temperature Range
5C - 50C

Mounting
Skid Mounted on MS/SS Frame

Design Standard
ASME / BIS / ISO Certified Process Design

Service Support
Onsite Commissioning & Maintenance

Safety Features
Low Pressure/High Pressure Cut-off, Dry Run Protection

Weight
Approx. 450-600 kg (dry)

Control Panel
Automated Control with Indicators

3000 LPH RO Plant Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About 3000 LPH RO Plant

The 3000 LPH RO Plant stands out as a monumental water purification solution, highly recommended for industrial, commercial, and institutional applications. This advanced system utilizes 8" x 40" polyamide membranes (4/5 units), achieving a noteworthy system recovery rate of 60%-70% and an unbeatable purity level of up to 99.5%. Equipped with ASME/BIS/ISO certified design standards and key safety features like low/high-pressure cut-off and dry run protection, it ensures reliable, low-maintenance operations. Advance purchase is urged for those seeking superior, skid-mounted, and prefabricated performance for borewell, tap, or municipal water sources.

Robust Plant for Diverse Applications

Used for the purification of water, the 3000 LPH RO Plant is tailored for industrial, commercial, and institutional needs. It finds application in drinking water bottling, food processing, pharmaceuticals, and hotels. Noteworthy extra features include a fully automated control panel with indicators, optional UV sterilization and ozonation, and comprehensive safety mechanisms. This highly efficient plant ensures consistent water quality, supporting operations demanding the strictest standards of hygiene and reliability.

FOB Port, Secure Packaging, and Sample Availability

Our 3000 LPH RO Plant proposal amount reflects both the scale and innovation embedded in its design. Plants are dispatched from India's notable freight ports, ensuring prompt delivery worldwide. Packaging is secure and robust, safeguarding the plant against potential expenditure on transit damages. Sample units are available upon request, facilitating pre-purchase assessment and peace of mind before full-scale implementation.

FAQ's of 3000 LPH RO Plant:

Q: How does the 3000 LPH RO Plant ensure high water purity?

A: The plant utilizes advanced polyamide RO membranes and multistage filtration, including multigrade sand, activated carbon, and micron filters. It achieves a water purity level of up to 99.5%, suitable for sensitive industrial and commercial applications.

Q: What types of water sources can the 3000 LPH RO Plant treat?

A: This RO plant is engineered to handle borewell, tap, and municipal water sources, making it versatile for a wide range of industrial and institutional settings.

Q: When is advance purchase advised for this RO system?

A: Advance purchase is highly recommended for organizations requiring timely installation, especially for projects with strict operational deadlines or high-volume water needs.

Q: Where does the installation and commissioning support occur?

A: Onsite commissioning and maintenance support are provided at the client's location, ensuring seamless installation and continued operational excellence.

Q: What are the main benefits of the plant's automated controls?

A: Automated controls with indicators offer user-friendly operation, real-time system monitoring, and early warning for any anomalies, contributing to operational safety and efficiency.

Q: How does the plant handle operational safety?

A: The plant includes safety features such as low and high-pressure cut-off, and dry run protection, minimizing risks and potential damage during operation.
